StratEdge Unlocks High-Power Electronics with Advanced Packaging

SANTEE, CA – February 27, 2026 – As the world’s appetite for faster, more powerful, and more reliable electronic systems grows unabated, the unsung heroes of technological progress are often the microscopic enclosures that protect and empower them. StratEdge Corporation, a veteran leader in high-performance semiconductor packaging, is stepping into the spotlight to showcase its critical enabling technologies at two major industry exhibitions in March: the IMAPS Device Packaging Conference and GOMACTech.

The company’s focus on molded ceramic packages and innovative gold-plated tabs addresses a fundamental challenge in modern electronics: how to manage the immense power and heat generated by next-generation semiconductors, particularly those made from advanced materials like Gallium Nitride (GaN).

The Foundation of Performance: A Booming Market for Advanced Packaging

The technology StratEdge specializes in sits at the heart of a rapidly expanding industry. The advanced packaging market, which provides the essential housing and interconnection for semiconductor chips, is projected to surge from approximately $44 billion in 2026 to over $87 billion by 2035. This explosive growth is driven by the relentless demands of artificial intelligence (AI), high-performance computing (HPC), and the global rollout of 5G and next-generation wireless networks.

In these applications, the package is far more than a simple protective shell. It is an integral part of the system's performance, responsible for managing thermal loads, ensuring signal integrity at extremely high frequencies, and guaranteeing reliability in the most demanding conditions. As chips become more powerful and complex, often integrating multiple functions into a single device, the packaging itself must evolve to prevent performance bottlenecks. The telecom and infrastructure segment, in particular, is forecast to be the fastest-growing sector, propelled by the need for powerful AI accelerators and GPUs that push thermal and power-density limits.

Unleashing GaN: Solving the High-Power Thermal Puzzle

At the forefront of this evolution is the rise of compound semiconductors like Gallium Nitride (GaN). GaN devices can operate at higher voltages and currents than their silicon-based counterparts, enabling unprecedented power density and efficiency in applications ranging from 5G base stations to advanced military radar systems. However, this power comes at a cost: intense heat generation that can degrade performance and shorten a device's lifespan if not managed effectively.

StratEdge is addressing this critical thermal challenge with its specialized gold-plated tabs and expertise in eutectic die attachment. This process uses a gold-tin (AuSn) or gold-silicon (AuSi) solder alloy to create an exceptionally strong and thermally conductive bond between the semiconductor die and its substrate. The company has refined a proprietary technique involving mechanical agitation during the bonding process, which minimizes voids and creates a thinner, more uniform bond line. This optimization dramatically improves heat transfer away from the active region of the GaN chip, boosting efficiency, increasing power output, and enhancing long-term reliability.

Furthermore, these tabs enable a chip-on-board (COB) workflow that expands the use of high-power devices. The GaN die is first attached to the tab, which then can be installed onto a larger, often organic, circuit board. This is crucial because many common organic board materials cannot withstand the high temperatures required for eutectic die attachment, a problem this two-step process elegantly solves. This approach is detailed in the company's new white paper, 'Die-on-Tab for Compound Semiconductors: Enabling Advanced RF Power Systems.'

Built for Extremes: MIL-STD Reliability in Mission-Critical Systems

While managing power is one side of the coin, ensuring unwavering reliability is the other, especially for systems deployed in harsh environments. For the defense, aerospace, and satellite communications sectors, component failure is not an option. StratEdge’s molded ceramic packages are engineered specifically for these mission-critical applications, offering reliability that meets stringent military standards (MIL-STD).

With over 200 standard outlines, the MC Series of molded ceramic packages provides robust solutions for RF and microwave applications operating up to 18 GHz. A key differentiator for StratEdge is its use of post-fired, or hardened, ceramic. Unlike co-fired ceramic, which can exhibit inconsistent shrinkage during manufacturing, post-fired ceramic provides complete dimensional stability and precise mechanical tolerances. This results in superior electrical performance with exceptionally low signal loss, even at frequencies extending to 63+ GHz.

These ceramic packages provide a hermetically sealed environment that protects sensitive semiconductor devices from moisture, contamination, and the vacuum of space. This level of protection is vital for the long-term integrity of satellite communication systems, avionics, and sophisticated radar arrays. The company's presence at GOMACTech, a conference with a strong government and defense focus, underscores the importance of these high-reliability solutions for national security applications.

Bridging Design and Manufacturing for Next-Generation Systems

With over four decades of experience, StratEdge has cultivated deep expertise in balancing the competing demands of performance, reliability, and manufacturability. The company's ITAR registration and ISO 9001:2015 certification further cement its position as a trusted partner in high-stakes industries.

“Our team is ready to help engineers evaluate die-on-tab workflows and packaging options that balance power, reliability, and manufacturability,” said Casey Krawiec, VP of Sales at StratEdge. “As a designer and manufacturer of packages for high-frequency, high-power, and high-reliability devices for over 40 years, we at StratEdge certainly are proponents of the use of packages. But we understand why designers of systems operating in Ku through E bands may decide the advantages of using a tab for COB outweigh the disadvantages.”

As StratEdge prepares to engage with engineers and program managers at the IMAPS and GOMACTech conferences, its message is clear: the path to the next generation of advanced electronics runs directly through innovations in packaging. By providing the foundational components that allow cutting-edge semiconductors to perform at their peak potential, the company is not just selling parts, but enabling the future of communication, defense, and computation.
